These flameproof electrical apparatus comply with European Directive ATEX 94/9/EC, for group II and category 2 GD. They are suitable for a variety of uses in hazardous zones 1, 2, 21 and 22 in which the use of flameproof instrument is required. The sensing element is a metallic diaphragm and acts directly on the microswitch through a self-centering pivot. The simplicity of the design, without levers, cams or similar mechanisms, gives the unit an exceptionally long working life.

• Industrial sector:  Chemical, Petrochemical,Energy,Oil & Gas,Engineering Procurement Construction (EPC)
• Instrument type: Pressure switches
• Specific applications: NACE version, ATEX version, Crystallizzing fluids, Viscous fluids, Corrosive fluids, Vacuum, Special overpressure, Combined (Vacuum + Pressure), Sedimentous fluids
• Conformity: NACE MR0103Directive ATEX 2014/34/UE
• Function: Electric contact
• Material: Stainless steel and alluminium alloys
• Process connection: Threaded
• Calibration range: 0...1 / 0...160bar
• Sensing element: Diaphragm
• Protection degree: IP 65
• Electrical switching: SPDT microswitch, one or two intervention
• Type of protection: EX db IIC T6 Ex tb IIIC T85°C
